Point-of-sale, self-service-signage, Commercial applications
Features
+ Metal shell material,flat and ultra-thin shape
+ Front frame against dust and liquids
+ Commercial grade LCD, LED backlight
+ Resolution 1920X1080FHD@60Hz
+ 10 point projective capacitive touchscreen
+ Cover plate anti riot and anti fingerprint
+ Rockchip RK3399 processor motherboard
+ 64-bit processor with the frequency of 2.0GHz
+ Supports horizontal and vertical display and touch
+ Supports 2.4ghz & 5Ghz dual-band WIFI
+ Support timing switch and remote monitoring
+ Back VESA wall mounting hole
+ Support OS: Android 9.0
+ 2-Year Warranty
Optional:
- No Touch
- AG Coating
- Resolution:3840X2160(4K）
- Media player box
- RK3288 processor
- Touchscreen Monitor
Specifications
Model
4320D
Color
Black/Silver
Diagonal
43 Inch
Active Area
941×529 (mm)
Dimensions
997×585×53.5 (mm)
Native Resolution
1920×1080FHD@60Hz
Aspect Ratio
16:9
Contract Ratio
1200:1
Number of Colors
16.7M
Brightness
LED: 400nits, PCAP:375nits
Viewing Angle
89°/89°/89°/89°
LED Response
8ms
Touch Technology
Projected capacitive touch screen -10 points
(Infrared Touch Optional)
Surface Hardness
7H (Mohs)
Touch Accuracy
≥2.5mm
Touch Interface
USB 2.0
Touch Response
12ms
CPU
RK3399, 6 core 64 bit, up to 2.0GHz
GPU
Mail-T860 GPU
Support OpenGL ES1.1/2.0/3.0/3.1,
OpenVG1.1,OpenCL,DX11
Memory
DDR3L 4GB
Storage
eMMC 32GB (16G/32G/64G/128G optional)
Network
1× LAN RJ45 (Gigabit)
WLAN
802.11b/g/n/ac, 2.4GHz & 5GHz dual-band
Bluetooth
Bluetooth 3.0
Speaker
2×5W (8Ω)
Watchdog
Supported
Timer Switch
Supported
Input Voltage
AC: 100-240 VAC, 50-60 Hz
I/O Interface
1×USB2.0, 1×USB3.0, 1×USB3.0 Type-C
1×HDMI, 1×RJ45, 1×TF slot, 1×SIM slot
1×DC, 1×MIC IN
Temperature
Operating: 0°C-40°C
Storage: -20°C-70°C
Humidity
Operating: 20%-80%
Storage: 10%-90%
Scalability
Seal between touch screen and frame
Drop Ball Test
450g ball falls from 1.2 meters without breaking
Shipping Dimensions
1100×650×150 (mm)
VESA Mounting
200×200mm, 400×400mm
MTBF
50,000 hours
OS System
Android 7.1/9.0
Agency Approvals
FCC, CE, ROHS
