3202E 32" Curved Touchscreen Monitor
Gaming, hospitality, business presentations, interactive advertising
Features
- All-aluminum body, narrow and thin frame
- The R1500 is curved comfort experience
- Colorful magic light bar dynamic display
- Multi-light strip (Supports up to 8 light strips)
- Resolution 1920X1080FHD@60Hz
- 10-touch Projection Capacitive Touchscreen
- Video interface: HDMI+VGA
- Supports standard VESA wall mounting
- 2-Year warranty
Optional:
No Touch
No light bar
Multi-light strip
Specifications
Model
3202E
Diagonal
32”
Aspect Ratio
16:9
Physical shape
Curved, R1500
Display area
699.4x393.85(mm)
Dimensions
763.74x455.45x103.34(mm)
Resolution
1920X1080FHD@60Hz
Viewing Angle
Horizontal: 89° /89°, Vertical: 89° /89°
Number of Colors
16.7M
Brightness (typical)
LCD panel : 350nits; PCAP : 315nits
Contrast Ratio
1400:1
Touch Technology
PCAP (Projected Capacitive Touchscreen)
Number of Touches
10-touch
Surface treatment
Hot Bending Process (Physics)
TP thickness
2.55mm(±0.3mm)
Transmittance
≥85%
Response time
10ms
Touch Interface
1*USB 2.0
Video Interface
1*VGA,1*HDMI
Light bar Interface
Option(Calling the debug interface)
Speaker
Option
Control
Display: OSD
Light bar: Remote
Input voltage range
100-240 VAC,50/60 Hz
Power
Built-in AC
Temperature
Operating: 0°C ∼ 40°C, Storage: 20°C to 60°C
Humidity
Operating: 20% to 70%; Storage: 10% to 80%
MTBF
50,000 hours demonstrated
Mounting Options
VESA two groups of holes:75mm&100mm
Weight
Packaged:17KG
Packing Dimension
855X555X220(mm)
What's in the Box
1*1.8m USB cable,1*1.8m HDMI cable,1*1.8m AC cable 1*Remote(option)
Agency Approvals
FCC, CE, ROHS
