5502E 55" Curved Touchscreen Monitor
Gaming, hospitality, business presentations, interactive advertising
Features
- All-aluminum body, narrow and thin frame
- The R1500 is curved comfort experience
- Colorful magic light bar dynamic display
- Multi-light strip (Supports up to 8 light strips)
- Resolution 1920X1080FHD@60Hz
- 10-touch Projection Capacitive Touchscreen
- Video interface: HDMI+VGA
- Supports standard VESA wall mounting
- 2-Year warranty
Optional:
No Touch
No light bar
Multi-light strip
Specifications
Model
5502E
Diagonal
55’’
Aspect Ratio
16:9
Physical shape
Curved, R1500
Display area
1210.2x 681(mm)
Dimensions
1269.5x745.6x52.7(mm)
Resolution
1920X1080FHD@60Hz
Viewing Angle
Horizontal: 89° /89°, Vertical: 89° /89°
Number of Colors
16.7M
Brightness (typical)
LCD panel : 350nits; PCAP : 315nits
Contrast Ratio
1000:1
Touch Technology
PCAP (Projected Capacitive Touchscreen)
Number of Touches
10-touch
Surface treatment
Hot Bending Process (Physics)
TP thickness
2.55mm(±0.3mm)
Transmittance
≥85%
Response time
10ms
Touch Interface
1*USB 2.0
Video Interface
1*VGA,1*HDMI
Light bar Interface
Option(Calling the debug interface)
Speaker
Option
Control
Display: OSD
Light bar: Remote
Input voltage range
100-240 VAC,50/60 Hz
Power
Built-in AC
Temperature
Operating: 0°C ~ 40°C, Storage:-20°C to 60°C
Humidity
Operating: 20% to 70%; Storage: 10% to 80%
MTBF
50,000 hours demonstrated
Mounting Options
VESA two groups of holes:200mm&400mm
Weight
Packaged:25KG
Packing Dimension
1345X830X210(mm)
What's in the Box
1*1.8m USB cable,1*1.8m HDMI cable,1*1.8m AC cable 1*Remote(option)
Agency Approvals
FCC, CE, ROHS
Accessories
Enhancements, expansions, and extras.
Resources
- 5502E Specification & Drawing
