2402E 23.6" Curved Touchscreen Monitor
Gaming, hospitality, business presentations, interactive advertising
Features
- All-aluminum body, narrow and thin frame
- The R1500 is curved comfort experience
- Colorful magic light bar dynamic display
- Multi-light strip (Supports up to 8 light strips)
- Resolution 1920X1080FHD@60Hz
- 10-touch Projection Capacitive Touchscreen
- Video interface: HDMI+VGA
- Supports standard VESA wall mounting
- 2-Year warranty
Optional:
No Touch
No light bar
Multi-light strip
Specifications
Model
2402E
Diagonal
23.6”
Aspect Ratio
16:9
Physical shape
Curved, R1500
Display area
522×294(mm)
Dimensions
598.59×363×84.25(mm)
Resolution
1920X1080FHD@60Hz
Viewing Angle
Horizontal: 89° /89°, Vertical: 89° /89°
Number of Colors
16.7M
Brightness (typical)
LCD panel : 300nits; PCAP : 255nits
Contrast Ratio
1000:1
Touch Technology
PCAP (Projected Capacitive Touchscreen)
Number of Touches
10-touch
Surface treatment
Hot Bending Process (Physics)
TP thickness
2.55mm(±0.3mm)
Transmittance
≥85%
Response time
10ms
Touch Interface
1*USB 2.0
Video Interface
1*VGA,1*HDMI
Light bar Interface
Option(Calling the debug interface)
Speaker
Option
Control
Display: OSD
Light bar: Remote
Input voltage range
100-240 VAC,50/60 Hz
Power supply
DC: 12V4A(5.5*2.1)
Temperature
Operating: 0℃ ~ 40℃
Storage:-20℃ to 60℃
Humidity
Operating: 20% to 70%
Storage: 10% to 80%
MTBF
50,000 hours demonstrated
Mounting Options
VESA two groups of holes:75mm&100mm
Weight
Packaged:7.85KG
Packing Dimension
710X480X150(mm)
What's in the Box
1*1.8m USB cable,1*1.8m HDMI cable,1*1.8m DC cable 1*Power adapter, 1*Remote(option)
Agency Approvals
FCC, CE, ROHS
