Specifications
Model
TDS1901P
Color
Black
Diagonal
19"
Aspect Ratio
5:4
Active Area
376 x 301(mm)
Dimensions
440 x 365 x 67(mm)
Resolution
1280X1024@60Hz
Viewing Angle
Horizontal: 89°/89°,
Vertical: 89°/89°
Number of Colors
16.7M
Brightness (typical)
LCD Panel: 300 nits, PCAP: 275 nits
Response Time
8ms
Contrast Ratio
1000:1
Touch Technology
PCAP (Projected Capacitive) - 10 Touch
Input method
Finger, Capacitance pen(Standard)
Latex gloves touch (pre commissioning required)
Transmittance
≥90%
Surface hardness
7H(Mohs)
Touch Interface
USB2.0
Video Interface
VGA+HDMI
Speakers
TwoX2W internal speakers
Input Voltage
AC:100-240 VAC, 50/60 Hz
Sealability
Touchscreen sealed to bezel
Drop Test
450g steel ball falls from 1m without breaking
Weight
(Unpackaged) 6KG
Shipping Dimensions
570 x 400 x 45(mm)
Operating Temperature
0°C to 40°C
Storage Temperature
-20°C to 60°C
Humidity
Operating: 20% to 70%; Storage: 10% to 80%
MTBF
50,000 hours demonstrated
Mounting Options
VESA:75X75(mm),1
00X100(mm)
Base Adjustable Angle
0-90 degree(Optional)
Power Supply
DC:12V3A
Warranty
3-years
Agency Approvals
FCC, CE, ROHS
Support OS
Windows,Linux,Android
What's in the Box
1*USB cable,1*HDMI cable,1*DC cable
